Very large figures (3/4") make these counters unmatched in character/figure size and easy to read at a distance. Simple, rugged, reliable base mount totalizers that even today embody the original time-tested design.

1127 Series - Direct Drive
Adds 10 counts for each drive shaft revolution in specified rotation. Subtracts for opposite rotation if reset knob is unobstructed.
Unit of Measure

Technical Specs

Brands

 N/A
Veeder-Root

Model

 N/A 1127/1128/1129/1130/1131/1132

Type

 N/A Mechanical Counter

Direct Torque

 N/A 2.5 oz·in

Revolution Torque

 N/A 1.5 oz·in

Number of Figures

 N/A 5 (Standard). Special Options Available.

Size of Figures

 N/A 0.750 in. high by 0.605 in. wide

Color of Figures

 N/A White on Black (Standard)
Special variations available.

Character Configuration

 N/A 0 to 9. Decimal point, stationary zero, cursor line, graduations, special variations available

Reset

 N/A Manual Reset Knob

Lubrication

 N/A Not Required

Mounting

 N/A Base

Construction

 N/A Case: Steel End Caps: Glass-Filled Nylon Pinions: Nylon Shafts: Chrome Plated Steel Wheels: Aluminum and Steel

Weight

 N/A 4 lb1.8 kg

Additional Information

N/A 1128 Series - Revolution Drive
Adds 1 count for each drive shaft revolution in specified rotation. Subtracts for opposite rotation if reset knob is unobstructed.

1129 Series - Ratchet Drive
Adds 1 count for each drive shaft revolution through 36 to 47 degrees arc. Max travel limited. Internal lever return spring.

1130 Series - Direct Drive, Non-Reset
Available as nonstock

1131 Series - Revolution Drive, Non-Reset
Available as nonstock

1132 Series - Ratchet Drive, Non-Reset
Available as nonstock

Features

N/A

  • Well defined 3/4 inch (19.0 mm) numbers
  • Five decades - counts to 99,999
  • Steel case and chrome on steel shaft
  • Lubrication never required
  • Base mounting configuration
  • Easy installation
  • Low maintenance
