Technical Specs

Brands

 N/A
Autonics

Model

 N/A BFX

Type

 N/A Amplifier

Current Consumption

 N/A ≤ 50 mA

Protection Circuit

 N/A Reverse power protection circuit, output short over current protection circuit, surge protection circuit

Insulation Resistance

 N/A ≥ 20 MΩ (500 VDC, Megger)

Dielectric Strength

 N/A Between the charging part and the case: 1,000 VAC ~ 50/60 Hz for 1 minute

Display Part

 N/A Dual Display

Function

 N/A General Type

Vibration

 N/A 1 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours

Shock

 N/A 500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times

Ambient Temperature

 N/A -10 to 50 ºC, Storage: -20 to 70 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation)

Connection

 N/A Connector Cable

Certification

 N/A

Features

N/A

  • Dual-display for light incident level and setting value
  • Enables to detect the minute object with 1/10,000 high resolution
  • Enables to detect with high-speed moving object (response time 50 ㎲)
  • 5 response times: ultra fast mode (50 µs), fast mode (150 µs), standard mode (500 µs), long distance mode (4 ms), ultra long distance mode (10 ms)
  • Anti-saturation setting function prevents malfunction by saturated light
  • External input: emitter OFF, remote sensitivity setting, peak reset, output ON/OFF/Keep, energy saving OFF
  • Multiple sensitivity setting modes available: auto tuning (fine-adjusting sensitivity) teaching sensitivity setting (button or external input auto-tuning, 1-point, 2-point, positioning)
