The Veeder-Root brand C628 Position Indicator is a member of a family of 1/8 DIN instruments which offer breakthrough display technology as well as easy-to-program user setup. The large LED display features the ability to change color based on process status such as exceeding the high alarm value. Therefore, when monitoring actual position status or another critical value, the C628 provides operators with an instant visual alert to changes in the application’s status.
Unit of Measure

Technical Specs

Brands

 N/A
Veeder-Root

Model

 N/A C628-PI

Type

 N/A Position Indicator

Height

 N/A 96 mm

Width

 N/A 48 mm

Depth

 N/A 110 mm

Mounting

 N/A Panel mount (mounting bracket supplied), 45 mm x 92 mm cutout

Connections

 N/A Screw Type Terminals - Combination Head

Operating Temperature

 N/A 32 to 131 ºF0 to 55 ºC

Storage Temperature

 N/A - 20 to 80 ºC- 4 to 176 ºF

Front Panel Rating

 N/A National Electrical Manufacturers Association (NEMA) 4X/International Electrotechnical Commission (IEC) Ingress Protection (IP65)

Non-Condensing Relative Humidity

 N/A 20 to 95 %

Weight

 N/A 0.56 lb

Additional Information

N/A The C628 Elapsed Timer has a definable set value at which an output will activate. The unit can be programmed to operate in a cumulative (elapsed time continues to accumulate during all instances when the input is active) or single (time value will display the elapsed time of an individual input and will reset to zero for each successive new pulse) input function mode. In addition, the time format (seconds, minutes, hours, minutes & seconds, or hours & minutes) and timing direction (up or down) can be selected.

Features

N/A

  • AWESOME 0.71" high digit LED display (27% larger than other 1/8 DIN units) Programmable color change display based on an event
  • Programmable help function and secondary legend display
  • High and low alarm outputs
  • Optional linear output relative to position
  • Accepts encoder inputs
  • Reset to a value other than zero enables establishment of a home position
  • Filter speed settable for 20, 200, or 10,000 Hz
  • Standard Outputs: 2 NPN transistors & 1 relay (optional 2nd relay)
  • Front panel reset enable and alarm lockout
  • Optional RS-485 plug in card
  • CE approved, UL, CUL recognized
