A very popular family of flange mount case, 5-figure nonreset totalizers. All models feature a scratch resistant front crystal, smooth low torque operation, and dust resistant construction.

These counters are compact non-reset counters available with ratchet drive, revolution drive, direct drive or rotary ratchet drive. All these technologies are in the same miniature form factor and can fit in a 1” cube exclusive of flanges. Can be clipped in or clamped to eliminate the need for mounting provisions/flanges.
Unit of Measure

Technical Specs

Brands

 N/A
Veeder-Root

Model

 N/A 7458/7459/7460/7461

Type

 N/A Case Counter

Number of Figures

 N/A 5

Height

 N/A 0.170 in4.3 mm

Width

 N/A 0.087 in2.2 mm

Color of Figures

 N/A White on Black

Lubrication

 N/A Not Required

Ambient Temperature

 N/A -40 to 160 ºF-40 to 57 ºC

Weight

 N/A 0.49 oz

Additional Information

N/A Models are available with input shaft drives which count from a ratcheting motion, or rotary drives with count per revolution ratios of 1:1, 10:1, or 1:10.

Features

N/A

  • Precision design provides smooth operation and long service life
  • Easy to see display - High contrast white-on-black figures
  • Scratch resistant front crystal
  • Stainless steel drive shaft; Tough molded case and internal parts
  • Lubrication never required
  • Compact and lightweight
