Bold 5-figure display and smooth rotary reset highlight this series of industrial grade totalizers. Other features include long-life bearings and 0.25" (6.35 mm) shaft, permitting use of our measuring wheels for linear footage totalizing applications. Counting is bidirectional on rotary input models.

Many optional configurations are possible, such as: 3, 4, 6, 7, or 8 figures; custom wheel colors; special shaft lengths.
Unit of Measure

Technical Specs

Brands

 N/A
Veeder-Root

Model

 N/A 7428/7430

Type

 N/A Medium Sized Totalizer

Number of Figures

 N/A 5

Height

 N/A 0.270 in6.86 mm

Width

 N/A 0.185 in4.70 mm

Color of Figures

 N/A White on Black

Reset

 N/A Manual Knob

Lubrication

 N/A Not Required

Mounting

 N/A Base

Construction

 N/A Case: C.A.B. plastic Drive Shafts: Plated Steel End Caps: Zamak Internal Parts: Acetal resin and A.B.S. plastic and sintered metal

Weight

 N/A 170 g6 oz

Features

N/A

  • Base mount with right-hand shaft position
  • 5 highly visible white-on-black figures - counts to 99,999
  • Choice of drive - revolution or direct
  • Bidirectional counting with direct and revolution drives
  • Convenient, low torque, rotary knob reset to zero
  • Tough, industrial duty construction
  • Long life bearings
  • No Lubrication required
