The 7298 Series is high speed with a quick reset counter. Exacting design specifications and manufacturing standards make this high speed totalizer appropriate for continuous operation at rates to 6000 counts per minute (ball bearing model). Its unique short-stroke, antiscramble, lever-reset mechanism assures correct wheel registration at every operation. Its double shaft extension accepts dual measuring wheels for linear measuring applications - providing reliable, stable contact with the measured material.
Unit of Measure

Technical Specs

Brands

 N/A
Veeder-Root

Model

 N/A 7298

Type

 N/A High Speed Counter

Drives

 N/A Geared Drive, adds one count for drive shaft revolution, subtracts in opposite rotation

Speed

 N/A Sleeve Bearings: 4000 rpm or cpm continuous; Ball Bearings: 6000 rpm or cpm continuous

Shaft Diameter

 N/A 0.312 in. (7.9 mm); (when used with measuring wheel, requires wheel with 0.313 in. bore.)

Maximum Torque

 N/A 4 oz·in

Gearing

 N/A 1:1

Number of Figures

 N/A 5

Height

 N/A 0.256 in6.5 mm

Width

 N/A 0.160 in4.1 mm

Color of Figures

 N/A White on Black

Reset

 N/A Manual Lever

Lubrication

 N/A Not Required

Mounting

 N/A Base

Operating Temperature

 N/A -18 to 55 ºF0 to 131 ºC

Construction

 N/A Bearings: Porous Bronze Sleeve or Precision Ball Case, Cover: Cast Aluminum Drive Gears: Steel, Brass or Acetal Resin Pinions: Nylon Shafts: Stainless Steel, 5/16" Diameter Wheels: Acetal Resin with Steel Gear and Heart Cam

Weight

 N/A 2 lb907 g

Additional Information

N/A Special models are available with options such as: special wheel colors, gear ratio variations, panel mounting.

Features

N/A

  • Fast lever-action reset is positive and reliable
  • High speed, bidirectional counting to 6000 cpm
  • 5 figures - high contrast white-on-black numerals
  • Geared drive mechanism for long, accurate, service life
  • Strong 5/16" (7.9 mm) stainless steel shaft
  • Double shaft extension is ideal for measuring wheels
  • Permanently lubricated, high reliability sleeve bearings
  • Ball bearing model for extra high speed operation
  • Ideal for high speed coil winding or linear measurement tasks
