7268 Series is frequently used for position indication on machine tools, back gauges, and laboratory equipment. It’s tough enough to be unaffected by punishing industrial environments, yet remains accurate and maintenance-free over a long service life.
Unit of Measure

Technical Specs

Brands

 N/A
Veeder-Root

Model

 N/A 7268

Type

 N/A High Speed Counter

Count Speed

 N/A 1500 rpm continuous, 2500 rpm intermittent

Maximum Static Torque

 N/A 0.21 N·cm0.3 oz·in

Number of Figures

 N/A 5 Standard; 3 to 7 Available, Non-Stock

Height

 N/A 0.187 in4.7 mm

Width

 N/A 0.140 in3.6 mm

Color of Figures

 N/A White on Black

Lubrication

 N/A Not Required

Mounting

 N/A Base

Operating Temperature

 N/A 0 to 131 ºF-18 to 55 ºC

Construction

 N/A Case: Brass Pinions: Acetal Resin Right Wheel: Nylon, All others Acetal Resin Shaft: Stainless steel

Weight

 N/A 198.45 g7 oz

Features

N/A

  • Speeds to 25,000 counts per minute
  • High contrast, easy-to-read, 5 figure display
  • Direct drive - adds 10 counts per shaft revolution, reverse rotation subtracts
  • Precision designed mechanism requires only 0.3 oz-in (0.21 N.cm) torque
  • Rugged construction with brass case and stainless steel shaft
  • Permanently lubricated oil impregnated porous bronze bushings
  • Available in left and right shaft extension, with clockwise addition or subtraction
  • Nonreset design provides security of counted totals
