Although its rugged diecast enclosure design appears similar to our general purpose electrical and mechanical-drive totalizers, the 7030 Series is unique because it counts pneumatic impulses. It is ideal where safety or environmental constraints make it difficult to use other counters - or where it’s just more convenient to obtain an air pressure signal, than to supply a voltage source or mechanical linkage.
Unit of Measure

Technical Specs

Brands

 N/A
Veeder-Root

Model

 N/A 7030

Type

 N/A General Purpose Counter

Number of Figures

 N/A 6

Height

 N/A 0.188 in4.78 mm

Color of Figures

 N/A White on Black

Reset

 N/A Manual Knob

Mounting

 N/A Base

Operating Temperature

 N/A 0 to 131 ºF-18 to 55 ºC

Construction

 N/A Case: Zamak Connection Fitting: Brass Wheels, Pinions: Acetal Resin

Weight

 N/A 1 lb0.454 kg

Features

N/A

  • Sturdy, industrial duty construction
  • 6 figures - counts to 999999 with rollover to zero
  • High contrast white-on-black numerals
  • Requires no electricity or mechanical coupling
  • Operates reliably from air sources of 40 to 150 psi
  • Smooth acting rotary reset mechanism
  • Pneumatic drive protected by internal exhaust filter
  • Count speed to 1000 counts per minute
  • Long service life
  • Popular, general purpose base mount configuration
