Available in several geared ratios, the 1953 Series is especially well suited for linear measurement of feet, yards, 1/8 yards, or meters. Its double ended shaft allows use of two measuring wheels - providing extra grip and stability of contact with measured material. It is commonly used in the textile, wire and cable, paper, rope, and sheet products industries.

The 1953 Series is designed and manufactured to provide years of trouble-free service in the most rigorous industrial applications. All models are right-hand drive, with types offered for addition in the clockwise, or counterclockwise direction. Opposite rotation subtracts.
Unit of Measure

Technical Specs

Brands

 N/A
Veeder-Root

Model

 N/A 1953

Type

 N/A Visicounter

Speed

 N/A 1,500 rpm5,000 rpm

Number of Figures

 N/A 6

Height

 N/A 0.345 in8.76 mm

Width

 N/A 0.250 in6.35 mm

Color of Figures

 N/A White on Black

Reset

 N/A Manual Knob: Rotary

Mounting

 N/A Base

Note for Speed

 N/A Whichever is limiting, when adding

Maximum Static Torque with 3:1 Ratio

 N/A 1.5 oz·in1.06 N·cm

Construction

 N/A Baseplate: Steel Bearings: Porous Bronze, Oil Impregnated Case and Worm Base: Zamak Right Angle Drive Shafts: Stainless Steel Wheel and Pinions: Acetal Resin Worm Gear: Brass Worm: Stainless Steel

Weight

 N/A 3 lb1.36 kg

Features

N/A

  • Precision linear measurement of all types of moving materials
  • Double stainless steel shafts accept dual measuring wheels
  • Black on white, 0.345" (8.8 mm) high figures for easy viewing
  • Heavy-duty die-cast and steel components
  • Corrosion and dust resistant - long life in demanding environments
  • Models with 3:1, 1:1, or 0.375:1 revolution-to-count ratio
  • Counts in yards, 1/8 yards, or feet using standard footage wheel
  • Counts in meters, using 1/3 meter wheel Smooth action rotary knob reset
