Additive operation - unique for mechanical predetermining counters. Resets to zero, counts up with output at a preset number. One set of wheels shows the current count, while a second set is used for quick and easy preset. Repeat operation for the same preset number, after manual reset.

Series 1239 provides economical control for many industrial operations - and it’s easy to install and use. When used with our accessory one-foot measuring wheels, it’s perfect for unattended material length control applications.
Unit of Measure

Technical Specs

Brands

 N/A
Veeder-Root

Model

 N/A 1239

Type

 N/A High Speed Counter

Drives

 N/A Geared drive, adds one count for each drive shaft revolution; will not subtract past zero

Speed

 N/A 2,500 rpm5,000 rpm

Maximum Static Torque

 N/A 4 oz·in

Number of Figures

 N/A 5

Color of Figures

 N/A Counting: White on Black
Predetermining: Gray with molded recessed figures

Reset

 N/A Manual, Resets to Preset Number

Lubrication

 N/A Periodic

Mounting

 N/A Base Mount with Switch at Back

Maximum Static Torque for 1:1 Gearing

 N/A 2.83 N·cm

Counting Width

 N/A 0.206 x 0.150 in5.23 x 3.81 mm

Predetermining Width

 N/A 0.165 x 0.120 in4.19 x 3.05 mm

Construction

 N/A Case: Zamak Cover: Steel Drive Shaft: Chrome Plated Steel Gears: Brass and Chrome Plated Steel Wheels, Pinions: Acetal Resin

Weight

 N/A 2 lb1.16 kg9 oz

Features

N/A

  • Heavy-duty base-mount enclosure
  • Highly visible white-on-black wheels
  • Unobtrusive gray preset wheels
  • 5 figures - count and preset to 99,999
  • Form-c output contacts with high current rating
  • Operation up to 5000 counts per minute
  • Preset is retained for next operation after reset
  • Protective hinged cover gives easy access to presets
  • Dust- and lint-resistant construction
  • 1/4 inch (6.35 mm) shaft accepts standard measuring wheel
