A time-proven, classic design. Choose the 1133, 1134 Series for your most punishing applications-even the count wheels consist of aluminum shells with steel engaging parts. Direct drive models use prelubricated bronze bearings which are capable of 1000 rpm continuous operation. Ball bearings used in the Revolution Drive model easily handle 2000 rpm, continuous. A brass housing and chrome-on-steel shaft ensure maximum strength and corrosion resistance.
Unit of Measure

Technical Specs

Brands

 N/A
Veeder-Root

Model

 N/A 1133/1134

Type

 N/A High Speed Counter

Maximum Static Torque

 N/A 0.71 N·cm1.0 oz·in

Number of Figures

 N/A 5

Height

 N/A 0.188 in

Width

 N/A 0.099 in

Color of Figures

 N/A White on Black

Reset

 N/A Manual wing nut; push-in engagement with 360º turn

Lubrication

 N/A Not Required

Mounting

 N/A Base

Drive Ratios

 N/A Direct Drive (1133 Series) adds ten counts for each drive shaft revolution in specified rotation, number 3 or 4 rotation only; subtracts for opposite rotation; pre-lubricated porous bronze sleeve bearings

Revolution Drive (1134 Series) adds one cou

Construction

 N/A Case: Brass End Caps: Zamak Gears, Pinions: Chrome Plated Steel Shaft: Chrome Plated Steel Wheels: Aluminum Shell, Steel Parts

Weight

 N/A 7 g198.6 oz

Features

N/A

  • Heavy-duty base mounting
  • High speed continuous operation
  • 5 white-on-black figures - counts to 99999
  • Available in Revolution drive & Direct drive
  • 1/4 inch (6.35 mm) shaft fits standard measuring wheels
  • Bidirectional counting
  • Convenient rotary reset to zero
  • All metal, tough industrial duty construction
  • No Lubrication required
