Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A LE8N |
Type |
N/A Timer |
Display Digits |
N/A 8-Digit |
Operation Method |
N/A Count Up |
Insulation Resistance |
N/A ≥ 100 MΩ (500 VDC, Megger) |
Dielectric Strength |
N/A Between the charging part and the case: 2,000 VAC ~ at 50/60 Hz for 1 minute |
Vibration |
N/A 0.75 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 1 hour |
Vibration (Malfunction) |
N/A 0.5 mm double amplitude at frequency of 10 to 55Hz in each X, Y, Z direction for 10 minutes |
Shock |
N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times |
Shock (Malfunction) |
N/A 100 m/s² (≈ 10 G) in each X, Y, Z direction for 3 times |
Ambient Temperature |
N/A -10 to 55 ºC, Storage: -25 to 65 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation) |
Certification |
N/A
 |
