Technical Specs

Brands

 N/A
Autonics

Model

 N/A FXM/FXH

Type

 N/A Counter/Timer

Maximum Counting Speed

 N/A 1 cps30 cps2,000 cps5,000 cps

Return Time

 N/A ≤ 500 ms

Permissible Voltage Range

 N/A 90 to 110 % of rated voltage

Memory Retention

 N/A ≈ 10 years (Non-volatile Semiconductor Memory type)

Insulation Resistance

 N/A ≥ 100 MΩ (500 VDC, Megger)

Vibration

 N/A 0.75 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 1 hour

Shock

 N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times

Ambient Temperature

 N/A -10 to 55 ºC, Storage: -25 to 65 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation)

Certification

 N/A

Features

N/A

  • Switch between counter and timer operation using DIP switch
  • No-voltage input (NPN) using DIP switch
  • Operation modes: count-up, count-down, count-up / down
  • Set decimal point, hr / min / sec display with RESET key

    • Counter
  • 20 input modes, 18 output modes

    • Timer
  • Various output modes (16 output modes)
  • Various time setting ranges:
    • 8-digit models: 0.01 sec to 99999 hr 59.9 min
    • 6-digit models: 0.1 sec to 99999.9 hr
    • 4-digit models: 0.01 sec to 9999 hr
  • Output model types: single preset, dual preset, indicator only
  • Power supply: 100 - 240 VAC~50 / 60 Hz
