Technical Specs

Brands

 N/A
Autonics

Model

 N/A SFEN

Type

 N/A Switch

Directing Opening Force

 N/A 30 N ± 10

Directing Opening Distance

 N/A 4.8 mm ± 0.5

Insulation Resistance

 N/A ≥ 100 MΩ (500 VDC, Megger)

Conditional Short Circuit Current

 N/A 100 A

Vibration (Malfunction)

 N/A 1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 10 minutes

Shock (Malfunction)

 N/A 150 m/s² (≈ 15 G) in each X, Y, Z direction for 3 times

Ambient Temperature

 N/A -10 to 55 ºC, Storage: -25 to 65 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation)

Certification

 N/A

Features

N/A

  • Models: Standard / Stop button / Momentary button type
  • High operation sensitivity with 3-position snap action
  • Enable operation indicator (green LED)
  • Various contact types
    • Standard type N.O. 2 + N.C. 1
    • Stop button type N.O. 2 + N.C. 2
    • Momentary button type N.O. 2 + N.O. 2
  • Secure connection with cable gland
  • Holding key SFEN-HK (sold separately): for connection with safety door switch (SFD Series)
