Technical Specs

Brands

 N/A
Autonics

Model

 N/A BW

Type

 N/A Sensor

Sensing Method

 N/A Through-Beam

Light Source

 N/A Infrared Light-Emitting Diode (LED) (850 nm modulated light)

Sensing Distance

 N/A 0.1 to 7.0 m

Sensing Target

 N/A Opaque Materials

Response Time

 N/A ≤ 10 ms

Operation Mode

 N/A Light ON

Protection Circuit

 N/A Reverse power protection circuit, output short overcurrent protection circuit

Insulation Resistance

 N/A ≥ 20 MΩ (500 VDC, Megger)

Dielectric Strength

 N/A Between the charging part and the case: 1,000 VAC ~ 50/60 Hz for 1 minute

Vibration

 N/A 1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 2 hours

Shock

 N/A 500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times

Certification

 N/A

Features

N/A

  • 20 mm optical pitch minimizes non-detection area (BW20)
  • Long sensing distance up to 7 m
  • 22 configurations (number of optics : 4 to 48/optical pitch : 20, 40 mm /detection area : 120 to 940 mm)
  • Mutual interference prevention function, self-diagnosis function, stable operation test
  • Bright LED indicators on emitter and receiver
  • Ambient illuminance : 100,000 lux (upgraded feature)
  • IP65 protection structure (IEC standard)
