Technical Specs

Brands

 N/A
Autonics

Model

 N/A BS4

Type

 N/A Photomicro Sensor

Sensing Type

 N/A Through-Beam

Sensing Distance

 N/A 5 mm

Sensing Target

 N/A Opaque Materials

Minimum Sensing Target

 N/A ≥ 0.8 x 1.8 mm

Hysteresis

 N/A ≤ 0.05 mm

Response Time

 N/A Received Light: ≤ 20 µs, Interrupted Light: ≤ 100 µs

Response Frequency

 N/A 2 kHz

Light Source

 N/A Infrared Light-Emitting Diode (LED)

Peak Emission Wavelength

 N/A 940 nm

Operation Mode

 N/A Built-in Light ON / Dark ON

Indicator

 N/A Operation Indicator (Red)

Certification

 N/A

Features

N/A

  • Minimize the external size with the assembled connector insertion part
    • Dedicated sold separately and universal connector cables available
    • Various shapes available for installation flexibility (K, L, R, T, TA, F, Y types)
  • Minimize malfunction and improved visibility
    • Minimize sensing part and body level to reduce malfunctions caused by foreign substances
    • Built-in operation indicators viewable from multiple directions
  • Selectable models for the operation of indicator
    • Indicator turns ON under the light received condition
    • Indicator turns ON under the light interrupted condition
  • Resistant structure for shock and vibration
    • Shock 15,000 m/s² (≈ 1,500 G), vibration 10 to 2,000 Hz (1.5 mm double amplitude)
  • Selectable operation modes (Light ON/Dark ON)
