Technical Specs

Brands

 N/A
Autonics

Model

 N/A BX

Type

 N/A Photoelectric Sensor

Operation Mode

 N/A Light ON Mode - Dark ON Mode Selectable (Switch)

Response Time

 N/A AC/DC power, relay contact output model: ≤ 20 ms
DC power, solid state (transistor) output model: ≤ 1 ms

Indicator

 N/A Operation Indicator (Yellow) Power Indicator (Yellow) Self-Diagnosis Indicator (Green)

Insulation Resistance

 N/A ≥ 20 MΩ (500 VDC, Megger)

Dielectric Strength

 N/A Between the charging part and the case: 1,500 VAC ~ 50/60 Hz for 1 minute

Vibration

 N/A 1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 2 hours

Shock

 N/A 500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times

Certification

 N/A

Features

N/A

  • Built-in sensitivity adjuster
  • Timer function (built-in timer model)
    • ON Delay, OFF Delay, One-shot Delay
  • NPN/PNP open collector simultaneous output (DC power Type)
  • Self-diagnosis function (green lights up in the stable level)
  • Built-in reverse power protection circuit and output short overcurrent protection circuit
  • Wide power supply range: Universal 24-240 VDC = / 24-240 VAC ~
  • IP65 protection rating (IEC standard)
