Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A BUP |
Type |
N/A Photoelectric Sensor |
Sensing Type |
N/A Through-Beam |
Operation Mode |
N/A Light ON Mode - Dark ON Mode Selectable (Control Wire) |
Response Time |
N/A ≤ 1 ms |
Light Source |
N/A Infrared |
Peak Emission Wavelength |
N/A 940 nm |
Indicator |
N/A Operation Indicator (Red) Power Indicator (Green) |
Insulation Resistance |
N/A ≥ 20 MΩ (500 VDC, Megger) |
Dielectric Strength |
N/A Between the charging part and the case: 1,000 VAC ~ 50/60 Hz for 1 minute |
Vibration |
N/A 1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Shock |
N/A 500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times |
Protection Circuit |
N/A Reverse power protection circuit, output short overcurrent protection circuit |
Sensing Target |
N/A Opaque Materials |
Certification |
N/A
 |
