Technical Specs

Brands

 N/A
Autonics

Model

 N/A BR

Type

 N/A Photoelectric Sensor

Sensing Distance

 N/A 200 mm

Sensing Type

 N/A Narrow Beam Reflective

Operation Mode

 N/A Light ON Mode - Dark ON Mode Selectable (Control Wire)

Response Time

 N/A ≤ 1 ms

Light Source

 N/A Infrared

Peak Emission Wavelength

 N/A 850 nm

Indicator

 N/A Operation Indicator (Red)

Sensing Target

 N/A Opaque Materials, Translucent Materials

Certification

 N/A

Features

N/A

  • Superior noise resistance with digital signal processing
  • High-speed response time under 1 ms
  • Built-in reverse power protection circuit and output short overcurrent protection circuit
  • Suitable for sensing in narrow space (narrow beam type)
  • External sensitivity adjustment
  • Light ON/Dark ON mode selectable by control wire
  • IP66 protection rating (IEC standard)
