Technical Specs

Brands

 N/A
Autonics

Model

 N/A BM

Type

 N/A Photoelectric Sensor

Direct Current (DC) Power Supply Voltage

 N/A 12 to 24 V

Output

 N/A Solid State (Transistor)

Response Time

 N/A ≤ 3 ms

Indicator

 N/A Operation Indicator (Red)

Insulation Resistance

 N/A ≥ 20 MΩ (500 VDC, Megger)

Dielectric Strength

 N/A Between the charging part and the case: 1,000 VAC ~ 50/60 Hz for 1 minute

Vibration

 N/A 1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 2 hours

Shock

 N/A 500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times

Protection Circuit

 N/A Reverse power protection circuit, output short overcurrent protection circuit

Ambient Temperature

 N/A -10 to 60 ºC, Storage: -25 to 70 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation)

Certification

 N/A

Features

N/A

  • Easy to mount at a narrow space with small size and light weight
  • Built-in external sensitivity adjuster (Diffuse reflective type only)
  • Easy to mount by screw type in mounting hole
  • Built-in reverse power protection circuit and output short overcurrent protection circuit
