Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A CR |
Type |
N/A Sensor |
Maximum Hysteresis of Sensing Distance |
N/A 20 % |
Standard Sensing Targe (Iron) |
N/A 50 x 50 x 1 mm |
Affection by Temperature |
N/A ±10% Max. for sensing distance at +20ºC within temperature range of -25 ~ +70ºC |
Insulation Resistance |
N/A Min. 50 MΩ (at 500 VDC, Mega) |
Dielectric Strength |
N/A 1500 VAC 50/60Hz for 1 minute |
Vibration |
N/A 1 mm amplitude at frequency of 10 ~ 55Hz in each of X, Y, Z directions for 2 hours |
Shock |
N/A 500 m/s² (50 G) in X, Y, Z direction for 3 times |
Indicator |
N/A Operation Indicator (Red LED) |
Ambient Temperature |
N/A -25 ~ +70 ºC (No Freezing Status) |
Storage Temperature |
N/A -30 ~ +80ºC (at non-freezing status) |
Ambient Relative Humidity |
N/A 35 to 95 % |
