Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A SFT |
Type |
N/A Terminal Block |
Continuous Current |
N/A 6 A |
Indicator |
N/A Operation Indicator: Green |
Insulation Resistance |
N/A ≥ 1,000 MΩ (at 500 VDC, Megger) |
Dielectric Strength (Coil-Contact) |
N/A 4,000 VAC ~ 50/60 Hz for 1 minute |
Vibration |
N/A 0.75 mm amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Vibration (Malfunction) |
N/A 0.75 mm amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 10 minutes |
Shock |
N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times |
Shock (Malfunction) |
N/A 150 m/s² (≈ 15 G) in each X, Y, Z direction for 3 times |
Ambient Temperature |
N/A -25 to 70 ºC, Storage: -30 to 80 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 25 to 85% RH, storage: 25 to 85% RH (No freezing or Condensation) |
Certification |
N/A
 |
Features
|
|
