Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A ACL |
Type |
N/A Terminal Block |
Insulation Resistance |
N/A ≥ 1,000 MΩ (500 VDC, Megger) |
Vibration |
N/A 0.75 mm amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Vibration (Malfunction) |
N/A 0.75 mm amplitude at frequency of 10 to 55Hz in each X, Y, Z direction for 10 minutes |
Shock |
N/A 150 m/s² (≈ 15 G) in each X, Y, Z direction for 3 times |
Shock (Malfunction) |
N/A 100 m/s² (≈ 10 G) in each X, Y, Z direction for 3 times |
Ambient Temperature |
N/A -15 to 55 ºC, Storage: -25 to 65 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation) |
Rated Voltage |
N/A ≤ 250 VDC =, 250 VAC~ 50/60 Hz |
Rated Current |
N/A ≤ 10 A |
Dielectric Strength |
N/A 3,000 VAC ~ 50/60 Hz for 1 minute |
Certification |
N/A
 |
