Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A SPB-A |
Type |
N/A Power Supply |
Insulation Resistance |
N/A Among all input terminals, all output terminals and PE: ≤ 100 MΩ (500 VDC, Megger) |
Dielectric Strength |
N/A
Among all input terminals and all output terminals: 3 kVAC~, Cutoff current = 20 mA Among all input terminals and PE: 2 kVAC~, Cutoff current = 20 mA Among all output terminals and PE: 1 kVAC~, Cutoff current = 20 mA |
Vibration |
N/A 10 to 55 Hz, 0.75 mm double amplitude, in each X, Y, Z direction for 2 hours |
Shock |
N/A 150 m/s² (≈ 15 G) in each X, Y, Z direction for 3 times |
Electromagnetic Interference (EMI) |
N/A Conforms to EN61000-6-4 |
Electromagnetic Susceptibility (EMS) |
N/A Conforms to EN61000-6-2 |
Ambient Humidity |
N/A 20 to 90% RH, storage: 20 to 90%RH (No freezing or Condensation) |
Indicator |
N/A Output Indicator (Green), Output Low-Voltage Indicator (Red) |
Certification |
N/A
 |
