Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A SPA |
Type |
N/A Power Supply |
Insulation Resistance |
N/A Between all inputs and outputs: ≤ 100 MΩ (500 VDC, Megger) |
Dielectric Strength |
N/A
Between all inputs and outputs: 3,000 VAC~50/60 Hz for 1 minute Between the charging part and the F.G.: 1,500 VAC~50/60 Hz for 1 minute |
Vibration |
N/A 10 to 55 Hz amplitude at frequency 0.75 mm in each X, Y, Z direction for 2 hours |
Shock |
N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times |
Electromagnetic Interference (EMI) |
N/A EN61000-6-4 conformation |
Electromagnetic Susceptibility (EMS) |
N/A EN61000-6-2 conformation |
Ambient Humidity |
N/A 25 to 85% RH, storage: 25 to 90% RH (No freezing or Condensation) |
Indicator |
N/A Output Indicator (Green) |
Certification |
N/A
 |
Features
|
|
