Technical Specs

Brands

 N/A
Autonics

Model

 N/A SP

Type

 N/A Power Supply

Output Power

 N/A 3 W

Input Frequency

 N/A 50 Hz60 Hz

Maximum Input Current Consumption

 N/A 0.15 A

Input Efficiency

 N/A 67 to 74 %

Output Indicator

 N/A Red Light Emitting Diode (LED)

Insulation Resistance

 N/A 100 MΩ (at 500 VDC, Megger)

Dielectric Strength

 N/A 2,000 VAC 50/60Hz for 1 minute

Vibration

 N/A 0.75 mm amplitude at frequency of 10 to 55Hz (for 1 min.) in each of X, Y, Z directions for 2 hours

Shock

 N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times

Environment

Ambient Temperature

 N/A -10 to 50 ºC, storage : -20 to 70 ºC

Ambient Relative Humidity

 N/A 35 to 85 %

Features

N/A

  • Compact size, high quality, cost-effective
  • Universal input power
  • Enables to drive various controllers
  • Built-in overcurrent protection circuit
  • DIN-rail mounting and mountable without the rail
