Technical Specs

Brands

 N/A
Autonics

Model

 N/A AiS-D

Type

 N/A Motor Driver

Insulation Resistance

 N/A ≥ 100 MΩ (500 VDC, Megger)

Dielectric Strength

 N/A Between the all charging part and the case: 1,00 VAC ~ 60 Hz for 1 minute

Vibration

 N/A 1.5 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours

Shock

 N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times

Ambient Humidity

 N/A 35 to 85% RH, Storage: 10 to 90% RH (No Freezing or Condensation)

Certification

 N/A

Features

N/A

  • Closed-loop system with real-time position control
  • High speed & high torque drive without missing steps
  • Easy operation setting with external adjuster (Gain, Speed filter, In-position, Resolution)
  • Built-in brake type motors available (AiS-D-B Series)
