Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A AiC-D-MT |
Type |
N/A Motor Driver |
Insulation Resistance |
N/A ≥ 100 MΩ (500 VDC, Megger) |
Dielectric Strength |
N/A Between the all charging part and the case: 1,000 VAC ~ 60 Hz for 1 minute |
Vibration |
N/A 1.5 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Shock |
N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times |
Ambient Temperature |
N/A 0 to 50 ºC, Storage: -10 to 60 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 10 to 90% RH (No Freezing or Condensation) |
Certification |
N/A
 |
