Technical Specs

Brands

 N/A
Autonics

Model

 N/A AHK

Type

 N/A Stepper Motor

Motor Shape

 N/A Hollow Shaft Type

Motor Phase

 N/A 5-Phase

Insulation Class

 N/A B Type (130ºC)

Insulation Resistance

 N/A Between the charging part and the case: ≥ 100 MΩ (500 VDC, Megger)

Dielectric Strength

 N/A Between the charging part and the case: 1,000 VAC ~ 50/60 Hz for 1 minute

Temperature Rise

 N/A ≤ 80ºC (5-phase excitation for rated current, while stop)

Ambient Temperature

 N/A -10 to 50 ºC, Storage: -25 to 85 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation)

Certification

 N/A

Features

N/A

  • Direct connection of Ball-screw, TM-screw and etc. without couplings
  • No resonance (vibration, noise) due to removed coupling
  • Low cost of applied system by improving the coupling accuracy and reducing the number of parts and installation process
  • Compact and light weight with high accuracy, high speed and high torque
  • Ideal for building compact sized system
