Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A SR1 |
Type |
N/A Relay |
Insulation Resistance |
N/A Input-output, input / output-case: ≥ 100 MΩ (500 VDC, Megger) |
Indicator |
N/A Input Indicator (Green) |
Vibration |
N/A 0.75 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 1 hour |
Vibration (Malfunction) |
N/A 0.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 10 minutes |
Shock |
N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times |
Shock (Malfunction) |
N/A 100 m/s² (≈ 10 G) in each X, Y, Z direction for 3 times |
Ambient Temperature |
N/A -30 to 80 ºC (in case of the rated input voltage VAC~: -20 to 70 ºC), storage: -30 to 100 ºC (No freezing or Condensation) |
Ambient Humidity |
N/A 45 ~ 85% RH, storage: 45 ~ 85% RH (No Freezing or Condensation) |
Input Terminal Fixed Torque |
N/A 0.75 to 0.95 N·m |
Certification |
N/A
 |
