Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A MP5S/MP5Y/MP5W |
Type |
N/A Meter |
Insulation Resistance |
N/A ≥ 100 MΩ (500 VDC, Megger) |
Dielectric Strength |
N/A Between the charging part and the case: 3,000 VAC~ 60 Hz for 1 minute |
Vibration |
N/A 0.75 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 1 hour |
Vibration (Malfunction) |
N/A 0.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 10 minutes |
Shock |
N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times |
Shock (Malfunction) |
N/A 100 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times |
Ambient Temperature |
N/A -10 to 50 ºC, Storage: -20 to 60 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation) |
Display Method |
N/A 7-Segment LED (zero blanking method) |
Noise Immunity |
N/A ± 2 kV the square wave noise (pulse width: 1µs) by the noise simulator |
Certification |
N/A
 |
Features
|
|
