Technical Specs

Brands

 N/A
Autonics

Model

 N/A MP5M

Type

 N/A Meter

Insulation Resistance

 N/A ≥ 100 MΩ (500 VDC, Megger)

Dielectric Strength

 N/A Between the charging part and the case: 3,000 VAC~ 60 Hz for 1 minute

Vibration

 N/A 0.75 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 1 hour

Vibration (Malfunction)

 N/A 0.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 10 minutes

Shock

 N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times

Shock (Malfunction)

 N/A 100 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times

Ambient Temperature

 N/A -10 to 50 ºC, Storage: -20 to 60 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation)

Display Method

 N/A 7-Segment LED (zero blanking method)

Character Width

 N/A 4 mm

Character Height

 N/A 8 mm

Noise Immunity

 N/A ± 2 kV the square wave noise (pulse width: 1µs) by the noise simulator

Certification

 N/A

Features

N/A

  • 14 operation modes
    • Frequency / revolutions / speed, passing speed, cycle, passing time, time interval
    • Time differential, absolute ratio, density, length measurement 1 / 2, interval
    • Accumulation, addition / subtraction (individual input), addition / subtraction (phase difference input)
  • Various output models
    • Relay single (high-limit) / double (high / low-limit) + NPN open collector output
  • Various functions
    • Prescale, monitoring delay, hysteresis, auto-zero, parameter lock
  • NPN input (non-contact / contact) or PNP input (non-contact / contact)
  • Display range: -19999 to 99999
  • Various display units
  • Power supply
    • 100 - 240 VAC~50 / 60Hz (AC type)
    • 24 VAC50 / 60 Hz, 24 - 48 VDC (AC / DC type)
