Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A L2RR |
Type |
N/A Pilot Light |
Installation |
N/A Extended |
Shock |
N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times |
Shock (Malfunction) |
N/A 100 m/s² (≈ 10 G) in each X, Y, Z direction for 3 times |
Vibration |
N/A 1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Vibration (Malfunction) |
N/A 1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 10 minutes |
Ambient Temperature |
N/A -15 to 55 ºC, Storage : -25 to 65 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, storage : 35 to 85% RH (No freezing or Condensation) |
Certification |
N/A
 |
