Technical Specs

Brands

 N/A
Autonics

Model

 N/A M4NN

Type

 N/A Meter

Resolution

 N/A 1/12,000

Display Scale

 N/A -1999 to 9999 (4-Digit)

Direct Current (DC) Load Voltage

 N/A ≤ 30 V

Load Current

 N/A ≤ 100 mA

Power Consumption

 N/A ≤ 3 W

Dielectric Strength

 N/A Between the charging part and the case: 3,000 VAC~ 50/60 Hz for 1 minute

Ambient Temperature

 N/A -10 to 50 ºC, Storage: -20 to 60 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation)

Certification

 N/A

Features

N/A

  • Various input / output options (by model)
    • Input options: DC voltage, DC current, AC voltage, AC current
    • Output options: NPN open collector / PNP open collector (default: indicator / no output)
  • Isolated input and power modules allow powering of multiple units using a single power supply
  • Display range: -1999 to 9999
  • High / low-limit display scale function
  • AC frequency measurement (range: 0.1 to 9999 Hz)
  • Preset output mode: OUT1, GO, OUT2 (NPN / PNP open collector output)
  • Power factor display function: displays analog input (1 - 5 V, 4 - 20 mA) from power factor converters as -0.50 to 1.00 to 0.50
  • Various functions: peak display value monitoring, display cycle delay, zero-point adjustment, peak display value correction
  • Power supply: 5 - 24 VDC, (isolated type)
