Technical Specs

Brands

 N/A
Autonics

Model

 N/A ENHP

Type

 N/A Pulse Generator

Resolution

 N/A 100 pulses/rev

Maximum Response Frequency

 N/A 10 kHz

Maximum Normal Allowable Revolution

 N/A ≤ 200 rpm

Maximum Peak Allowable Revolution

 N/A ≤ 600 rpm

Starting Torque

 N/A ≤ 0.098 N·m

Allowable Radial Shaft Load

 N/A ≤ 2 kgf

Allowable Thrust Shaft Load

 N/A ≤ 1 kgf

Dielectric Strength

 N/A Between the charging part and the case: 750 VAC, 50/60 Hz for 1 minute

Vibration

 N/A 1 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours

Shock

 N/A ≤ 50 G

Ambient Temperature

 N/A -10 to 70 ºC, Storage: -25 to 85 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 90% RH (No Freezing or Condensation)

Certification

 N/A

Features

N/A

  • Ideal for manual pulse input applications including NC machinery and milling machines
  • Emergency stop switch, enable operation switch
  • 6-position axis selector switch, 4-position rate selector switch
  • Resolution: 100 pulses per revolution
  • Power supply: 5 VDC, ± 5%, 12 - 24 VDC, ± 5%
