Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A ENH |
Type |
N/A Pulse Generator |
Resolution |
N/A 100 pulses/rev25 pulses/rev |
Maximum Response Frequency |
N/A 10 kHz |
Maximum Normal Allowable Revolution |
N/A ≤ 200 rpm |
Maximum Peak Allowable Revolution |
N/A ≤ 600 rpm |
Starting Torque |
N/A ≤ 0.098 N·m |
Allowable Radial Shaft Load |
N/A ≤ 2 kgf |
Allowable Thrust Shaft Load |
N/A ≤ 1 kgf |
Dielectric Strength |
N/A Between the charging part and the case: 750 VAC, 50/60 Hz for 1 minute |
Vibration |
N/A 1 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Shock |
N/A ≲ 50 G |
Ambient Temperature |
N/A -10 to 70 ºC, Storage: -25 to 85 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 90% RH (No Freezing or Condensation) |
Certification |
N/A
 |
