Request Quote
Unit of Measure

Technical Specs

Brands

 N/A
Autonics

Model

 N/A ENC

Type

 N/A Encoders

Minimum Measuring Unit

 N/A 1 mm1 cm1 m0.01 yd0.1 yd1 yd

Maximum Response Frequency

 N/A 180 kHz

Maximum Allowable Revolution

 N/A 5,000 rpm

Response Speed

 N/A ≤ 1 µs

Starting Torque

 N/A Dependent on the coefficient of friction

Dielectric Strength

 N/A Between the charging part and the case: 750 VAC ~ 50/60 Hz for 1 minute

Vibration

 N/A 1 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours

Shock

 N/A ≲ 75 G

Ambient Temperature

 N/A -10 to 70 ºC, Storage: -25 to 85 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 90% RH (No Freezing or Condensation)

Certification

 N/A

Features

N/A

  • Wheel type encoders ideal for measuring length or speed of continuously moving objects
  • Output waveform of measured distance is proportional to International Weights and Measures (meters / inches)
  • Power supply: 5 VDC, ± 5%, 12 - 24 VDC, ± 5%
