Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A E80 |
Type |
N/A Encoders |
Housing Diameter |
N/A 80 mm |
Resolution |
N/A 1,024 pulses/rev100 pulses/rev3,200 pulses/rev360 pulses/rev500 pulses/rev512 pulses/rev60 pulses/rev |
Maximum Response Frequency |
N/A 200 kHz |
Maximum Allowable Revolution |
N/A 3,600 rpm |
Starting Torque |
N/A ≤ 0.02 N·m |
Moment of Inertia |
N/A 8 x 10-5 kg·m²≤ 800 g/cm² |
Allowable Radial Shaft Load |
N/A ≤ 5 kgf |
Allowable Thrust Shaft Load |
N/A ≤ 2.5 kgf |
Dielectric Strength |
N/A Between the charging part and the case: 750 VAC ~ 50/60 Hz for 1 minute |
Vibration |
N/A 1 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Ambient Temperature |
N/A -10 to 70 ºC, Storage: -25 to 85 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 90% RH (No Freezing or Condensation) |
Certification |
N/A
 |
