Technical Specs

Brands

 N/A
Autonics

Model

 N/A E58

Type

 N/A Encoders

Housing Diameter

 N/A 58 mm

Resolution

 N/A 1 pulses/rev10 to 8,000 pulses/rev12 pulses/rev2 pulses/rev5 pulses/rev

Maximum Response Frequency

 N/A 300 kHz

Maximum Allowable Revolution

 N/A 5,000 rpm

Current Consumption

 N/A Totempole, NPN open collector, Voltage output: ≤ 80 mA (no load) Line driver output: ≤ 50 mA (no load)

Dielectric Strength

 N/A Between the charging part and the case: 750 VAC ~ 50/60 Hz for 1 minute

Vibration

 N/A 1 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours

Shock

 N/A ≲ 75 G

Ambient Temperature

 N/A -10 to 70 ºC, Storage: -25 to 85 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 90% RH (No Freezing or Condensation)

Ingress Protection (IP) Rating (International Electrotechnical Commission (IEC) Standard)

 N/A Ingress Protection (IP50)

Certification

 N/A

Features

N/A

  • Ø 58 mm flange incremental rotary encoders
  • Accurate measurement of angle, position, revolution, speed, acceleration, and distance
  • Shaft, hollow shaft, blind hollow shaft models available
  • Cable type, cable connector type, axial / radial connector types available
  • Various resolutions: 1 to 8000 pulses per revolution
  • Various control output options
  • Power supply: 5 VDC, ± 5%, 12 - 24 VDC, ± 5%
