Technical Specs

Brands

 N/A
Autonics

Model

 N/A BF4

Type

 N/A Amplifier

Maximum High Response Time

 N/A 0.5 ms

Response Time

 N/A Built-in 2 differential frequencies (frequency 1: ≤ 0.5 ms, frequency 2: ≤ 0.7 ms)

Sensitivity Setting

 N/A Button/Remote sensitivity setting

Operation Mode

 N/A Light ON/Dark ON Selectable

Indicator

 N/A Operation Indicator (Red), Stability Indicator (Green)

Current Consumption

 N/A ≤ 45 mA

Protection Circuit

 N/A Reverse power protection circuit, output short overcurrent protection circuit

Insulation Resistance

 N/A ≥ 20 MΩ (500 VDC, Megger)

Dielectric Strength

 N/A Between the charging part and the case: 1,000 VAC ~ 50/60 Hz for 1 minute

Certification

 N/A

Features

N/A

  • Auto sensitivity setting (button setting) / remote sensitivity setting type
  • External synchronization input, mutual interference protection, self-diagnosis
  • Reverse power protection and output short overcurrent protection circuit
  • Timer function: OFF delay timer approx. 40 ms fixed. (standard type, remote sensitivity setting type only)
  • Automatically selectable Light ON / Dark ON
  • Precise detection of small target and easy to install in the complicated place
