Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A PT-4PIN |
Type |
N/A Distribution Box |
Direct Current (DC) Using Power Supply Voltage |
N/A 10 to 30 V |
Direct Current (DC) Power Supply Voltage |
N/A 12 to 24 V |
Rated Current |
N/A 2 A (Per Signal), 4 A (Per Port), 10 A (Body) |
Leakage Current |
N/A ≤ 0.5 mA |
Connection Life Cycle |
N/A ≥ 200 Operations |
Dielectric Strength |
N/A 1500 VAC 50/60 Hz for 1 minute |
Vibration |
N/A 1.0 mm amplitude at frequency of 10 to 55Hz in each X, Y, Z direction for 2 hours |
Shock |
N/A 500 m/s2 (≈ 50 G) X, Y, Z in each X, Y, Z direction for 3 times |
Indicator |
N/A Operation Indicator: Red Power Indicator: Green |
Ambient Temperature |
N/A -25 to 75 ºC, Storage: -30 to 80 ºC (A Non Freezing or Condensation Environment) |
Ambient Humidity |
N/A 35 to 95 %RH, storage: 35 to 95 %RH (A Non Freezing or Condensation Environment) |
Certification |
N/A
 |
