Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A D5Y/D5W |
Type |
N/A Display Unit |
Permissible Voltage Range |
N/A 90 to 110 % of rated voltage |
Input Resistance |
N/A 100 MΩ (500 VDC, Megger) |
Maximum Clock |
N/A 100 Hz to 5 kHz |
Input Logic |
N/A Positive logic (PNP), negative logic (NPN) |
Noise Immunity |
N/A ± 1 kV the square wave noise (pulse width: 1 µs) by the noise simulator |
Dielectric Strength |
N/A Between the charging part and the case: 2,000 VAC ~ 50/60 Hz for 1 minute |
Vibration |
N/A 0.75 mm double amplitude at frequency of 10 to 55 Hz in each of X, Y, Z directions for 1 hour |
Vibration (Malfunction) |
N/A 0.5 mm double amplitude at frequency of 10 to 55 Hz in each of X, Y, Z directions for 10 minutes |
Shock |
N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times |
Shock (Malfunction) |
N/A 100 m/s² (≈ 10 G) in each X, Y, Z direction for 3 times |
Ambient Temperature |
N/A -10 to 50 ºC, Storage: -25 to 65 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation) |
Display Method |
N/A 7-Segment LED Display |
Certification |
N/A
 |
