Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A PG |
Type |
N/A Socket |
Rated Alternating Current (AC) Voltage |
N/A 250 V |
Rated Current (Resistance Load) |
N/A 7 A |
Insulation Resistance |
N/A ≥ 100 MΩ (500 VDC, Megger |
Dielectric Strength |
N/A 2,000 VAC~50/60 Hz for 1 minute |
Vibration |
N/A 0.75 mm amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 1 hour |
Shock |
N/A 980 m/s² (≈ 98 G) in each X, Y, Z direction for 3 times |
Ambient Temperature |
N/A -10 to 55 ºC, Storage: -25 to 65 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH (No Freezing or Condensation) |
Tightening Torque |
N/A 0.8 N·m |
Applied Screw |
N/A M3.5 |
Certification |
N/A
 |
