Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A B6MA |
Type |
N/A Melody Buzzer |
Permissible Voltage Range |
N/A 90 to 110 % of rated voltage |
Sound Pressure |
N/A Max. 105±10% dB (0.1 m), Max. 95±10% dB (1 m) |
Case Color |
N/A Gray |
Input |
N/A NPN Open Collector Model PNP Open Collector Model |
Channels |
N/A 4 Channels |
Melody Type |
N/A Terminal Input: 4 types (Ambulance, Police, Ringtone, for Elise) |
Insulation Resistance |
N/A ≥ 1,000 MΩ (500 VDC, megger, between all terminals and case) |
Installation Diameter |
N/A 66 mm |
Certification |
N/A
 |
Features
|
|
