Explosion-proof RX71 incremental encoders with a stainless steel housing have been designed specifically for use in potentially explosive atmospheres. The pressure-resistant housing has been developed in compliance with the EN 60079 series of standards for use in explosive atmospheres and is permitted for use in environments where there is a risk of gas or dust explosion, zones 1 and 21.
Unit of Measure

Technical Specs

Brands

 N/A
Hengstler

Model

 N/A RX71TI

Type

 N/A Incremental Encoder

Number of Pulses

 N/A 1 10 100 1000 10000 1024 1200 125 1250 128 144 15 150 1500 1600 180 1800 2 20 200 2000 2048 230 25 250 2500 256 3 30 300 3000 314 3480 35 350 360 3600 375 3750 3968 4 40 400 4000 4096 45 460 480 4800 5 50 500 5000 512 5400 60 600 6000 625 635 64 70 72 720 7200 750 7680 80 8000 8192 900 9000

Note for Number of Pulses

 N/A Other number of pulses on request.

Certification

 N/A

Mechanical

Housing Diameter

 N/A 70 mm

Shaft Diameter (Solid Shaft)

 N/A 10 mm

Flange (Mounting of Housing)

 N/A Clamping Flange Fastening Screw Thread 3x M6x12

Typical Starting Torque

 N/A < 1 N·cm

Approximate Moment of Inertia

 N/A 20 g/cm²

Housing Material

 N/A Stainless Steel

Maximum Axial Shaft Load

 N/A 40 N

Maximum Radial Shaft Load

 N/A 100 N

Applications

N/A Enamelling production line, surfacing machines, bottling machines, mixers, silo works, mills

Features

N/A

  • ATEX certification for gas and dust explosion proof
  • Resolution up to 10,000 ppr
  • Robust design
