The robust, economical RI64 hollow shaft incremental encoder stands out because it is the best value for money in its class. The insulated shaft coated with hard ceramic protects the bearings effectively against motor currents. The high ingress protection, IP67, also applies to through hollow shafts and, together with the unit's high resistance to impacts and vibrations, is suitable for use in tough ambient conditions. With a line count of up to 5000, this robust encoder is suitable not only for many industrial applications but, in particular, for use as a feedback encoder for asynchronous motors.
Unit of Measure

Technical Specs

Brands

N/A
Hengstler

Model

N/A RI64

Type

N/A Incremental Encoder

Number of Pulses

N/A 1000 1024 2000 2048 4096

Certification

N/A

Mechanical

Housing Diameter

N/A 63 mm

Shaft Diameter (Hub Shaft)

N/A 10 mm12 mm14 mm15 mm16 mm

Shaft Diameter (Hollow Shaft)

N/A 12 mm14 mm15 mm16 mm

Flange (Mounting of Housing)

N/A Tether

Mounting Depth

N/A 54 mm

Mounting of Shaft

N/A Front clamping ring, Rear clamping ring

Protection Class Shaft Input (EN 60529)

N/A Ingress Protection (IP64) Ingress Protection (IP67)

Protection Class Housing (EN 60529)

N/A Ingress Protection (IP64) Ingress Protection (IP67)

Maximum Speed

N/A Hub Shaft: max. 12,000 rpm
Through Hollow Shaft: max. 6,000 rpm

Housing Material

N/A Aluminum

Features

N/A

  • Through hollow shaft and hub shaft up to 16 mm
  • Up to 20,000 steps with 5,000 pulses
  • Robust design
  • High shock and vibrations resistance
  • Electrically insulated shaft: protection from shaft currents
  • Wide power supply range DC 5-26 V
