Small incremental rotary encoder for universal fitting in front or rear panel. High-grade ball-bearings ensure high performance and small start-up torque. This encoder is particularly suitable for such fields of application as miniature motors, laboratory equipment, labelling machines, plotters, linear encoders.
Unit of Measure

Technical Specs

Brands

 N/A
Hengstler

Model

 N/A RI38

Type

 N/A Incremental Encoder

Number of Pulses

 N/A 10 100 1000 1024 128 144 20 200 25 250 256 28 288 300 32 360 400 5 50 500 512 60 600 72 720 900

Note for Number of Pulses

 N/A Other number of pulses on request.

Certification

 N/A

Mechanical

Housing Diameter

 N/A 39 mm

Shaft Diameter (Solid Shaft)

 N/A 6 mm

Flange (Mounting of Housing)

 N/A Square Flange

Protection Class Shaft Input (EN 60529)

 N/A Ingress Protection (IP40)

Protection Class Housing (EN 60529)

 N/A Ingress Protection (IP50)

Axial Shaft Load

 N/A 5 N

Radial Shaft Load

 N/A 10 N

Maximum Speed

 N/A 10,000 rpm

Torque

 N/A ≤ 0.2 N·cm

Housing Material

 N/A Glass Fiber-Reinforced Plastic

Applications

N/A FHP motors, laboratory equipment, labelling machines, plotters, length

Features

N/A

  • Replacement for type RI 39
  • Encoder for universal installation by means of front/back panel mounting
  • High efficiency by means of ball bearing
  • Small torque
