Technical Specs

Brands

 N/A
Dynapar™

Hengstler

Model

 N/A AD 35

Type

 N/A Absolute Encoder

Code

 N/A Absolute

Resolution Single-Turn

 N/A 12 to 22 bits

Absolute Accuracy (±)

 N/A 35 in

Certification

 N/A

Mechanical

Housing Diameter

 N/A 38.1 mm

Maximum Speed (Continuous)

 N/A 10,000 rpm

Maximum Speed (Short Term)

 N/A 12,000 rpm

Features

N/A

  • Short Mounting Depth Allows Installation in Tight Motor Endbells
  • Up to 10,000 RPM Speed Capability for Majority of Servomotor Applications
  • 8 mm Hub shaft Mount for Easy Installation
