Technical Specs

Brands

 N/A
Dynapar™

Hengstler

Model

 N/A AD 34

Type

 N/A Absolute Encoder

Code

 N/A Absolute

Resolution Single-Turn

 N/A 12 to 22 bits

Resolution Multi-Turn

 N/A 12 bits

Absolute Accuracy (±)

 N/A 35 in

Certification

 N/A

Mechanical

Housing Diameter

 N/A 38.1 mm

Maximum Speed (Continuous)

 N/A 10,000 rpm

Maximum Speed (Short Term)

 N/A 12,000 rpm

Features

N/A

  • Special Notched Shaft Installs Easily in One Step and Eliminates Coupling Issues
  • Up to 22 bits of Singleturn Absolute Positioning
  • Wide -15º to +120ºC Operating Temperature Covers Majority of Servomotor Applications
