Type 150 is approved for use as an accurate length measuring device. In addition, this versatile device can, if required, also be used as a revolution or stroke counter. The 6-digit display guarantees easy readability. Type 150 also has a convenient reset button.
Unit of Measure

Technical Specs

Brands

 N/A
Hengstler

Model

 N/A 150

Type

 N/A Counter

Display

 N/A 6-Digit

Digit Height

 N/A 4 mm

Case

 N/A Black Glassfibre-Reinforced Plastic Polyamide (PA)

Approximate Weight

 N/A 70 g

Transmission Ratio

 N/A 1:1, 1:2 or 1:10, depending on version

Reset

 N/A With button, tactile touch 12 N
Key reset available on request

Cover

 N/A Gray Plastic Acrylonitrile Styrene Butadiene (ASB)

Warning

 N/A Don't push the reset pushbutton during the process

Maximum Stroke Rate

 N/A Revolution counter: 3000 rpm
Length counter 1500 rpm
500 strokes/min (stroke counter only)

Features

N/A

  • Approved for calibration applications by the PTB (German Federal Institute for Physics and Technology)
  • With button reset
  • Protection class IP 50
